RC 350 Hydraulic Compactor

Description



With high performance and low downtime, RC Hydraulic Compactors help you complete the job efficiently and effectively.

High Performance

The high compaction frequency combined with the high vibrating force make quick work of most jobs, including slope compaction.

Fits on Every Carrier

Six models are available for carriers from 1 to 40 tons, and easily attach with a standard or quick-change adapter.

Carrier Weight Class: 3-8 (6600-17600)
Service Weight: 320kg
Weight Without Adapter: 274kg
Length: 693mm
Width: 475mm
Height: 623mm
Baseplate Size: 475 x 693mm
Plate Coverage: 0.25m2
Vibrating Force: 2.3t
Operating Pressure: 150bar
Oil Flow: 57L/min
Sound Pressure Level: 67dB(A)
Sound Power Level: 106dB(A)
Port Connectors: 1-1/16″UNF Male
Minimum Hose and Pipe i.d: 12mm
Pipework Dia and Wall Thickness: 15 x 1.5mm
Hole Pattern Adapter: RX4, RX8

Contact Us For More Information About The RC 350 Hydraulic Compactor
