RC 450 Hydraulic Compactor

Description



With high performance and low downtime, RC Hydraulic Compactors help you complete the job efficiently and effectively.

High Performance

The high compaction frequency combined with the high vibrating force make quick work of most jobs, including slope compaction.

Fits on Every Carrier

Six models are available for carriers from 1 to 40 tons, and easily attach with a standard or quick-change adapter.

Carrier Weight Class: 4-9 (8800-19800)
Service Weight: 430kg
Weight Without Adapter: 387kg
Length: 929mm
Width: 610mm
Height: 622mm
Baseplate Size: 610 x 929mm
Plate Coverage: 0.42m2
Vibrating Force: 3.6t
Operating Pressure: 150bar
Oil Flow: 76L/min
Sound Pressure Level: 69dB(A)
Sound Power Level: 106dB(A)
Port Connectors: 1-1/16″UNF Male
Minimum Hose and Pipe i.d: 20mm
Pipework Dia and Wall Thickness: 25 x 2.5mm
Hole Pattern Adapter: RX4, RX8
