RC 850 Hydraulic Compactor

Description



With high performance and low downtime, RC Hydraulic Compactors help you complete the job efficiently and effectively.

High Performance

The high compaction frequency combined with the high vibrating force make quick work of most jobs, including slope compaction.

Fits on Every Carrier

Six models are available for carriers from 1 to 40 tons, and easily attach with a standard or quick-change adapter.

Carrier Weight Class: 9-20 (19800-44000)
Service Weight: 880kg
Weight Without Adapter: 726kg
Length: 1178mm
Width: 710mm
Height: 764mm
Baseplate Size: 710 x 1178mm
Plate Coverage: 0.63m2
Vibrating Force: 7.3t
Operating Pressure: 150bar
Oil Flow: 114L/min
Sound Pressure Level: 66dB(A)
Sound Power Level: 106dB(A)
Port Connectors: 1-1/16″UNF Male
Minimum Hose and Pipe i.d: 20mm
Pipework Dia and Wall Thickness: 25 x 2.5mm
Hole Pattern Adapter: RX11, RX14
